MIL-DTL-38999 Series I · catalog configuration
MS27466T17E06AN
MS27466T17E06AN is a Donconn Series I style wall-mount receptacle configuration. The catalog reference uses shell17, insert06 and six size12 contact positions, with normal keying. Donconn defines finishE as passivated stainless steel.
Product number MS27466T17E06AN
- Series
- Series I
- Shell / insert
- 17 / 06
- Contact positions
- 6 positions; 6×12
- Material / finish
- Passivated stainless steel (Donconn E ordering definition)
Description
MS27466T17E06AN is a Donconn Series I style wall-mount receptacle configuration. The catalog reference uses shell17, insert06 and six size12 contact positions, with normal keying. Donconn defines finishE as passivated stainless steel. Use the complete supplier configuration and controlled drawing to confirm the offered unit.
Configuration checklist
- Match the full ordering code and insert face to the supplied drawing.
- Confirm the mating half, contact gender, key position and coupling interface.
- Check shell style, rear configuration, cable exit and any accessory interface.
- Request the documents required for the offered unit; catalog values are not unit test results.
Technical Data
Ordering-code and insert data are catalog references. Electrical, environmental and mating-life values shown as catalog or family figures do not certify the supplied unit. Confirm the exact configuration and required evidence against its controlled drawing.
| Series and shell style | MIL-DTL-38999 Series I; Wall-mount receptacle |
|---|---|
| Shell size / insert arrangement | 17 / 06 |
| Contact quantity and size mix | 6 positions; 6×12 |
| Coupling | Bayonet |
| Contact / termination | Pin insert configuration (supplier listing) |
| Keying / option | N (normal keying) |
| Shell material and finish | Passivated stainless steel (Donconn E ordering definition) |
Applications
These are selection and sourcing contexts for the listed catalog configuration. Suitability depends on the equipment interface, operating conditions and supplied-item documentation.
Buyer Q&A
Which insert configuration is listed for MS27466T17E06AN?
The SeriesI catalog reference lists17-06 with six size12 contact positions. Confirm the offered contact supply with the complete supplier drawing.
Which material definition is used for MS27466T17E06AN?
This is a wall-mount receptacle in shell 17. Compare flange mounting, panel opening, seal placement and rear clearance against the controlled installation drawing.
How should contact and keying options be checked for MS27466T17E06AN?
Retain the complete AN supplier code, pin insert configuration and normal keying in the RFQ, and compare full mating-half drawings.
What should an RFQ include for MS27466T17E06AN?
Include MS27466T17E06AN, quantity, mating-half code, panel drawing, required supplied contacts and documents.
Similar Products
Compare adjacent catalog configurations and confirm mating, keying and rear interface by drawing.
MS27466T17E06AN · RFQ
Send the exact drawing and mating requirement
Include the mating part, cable or panel details, quantity and documentation required for your project.
