MS27505E19B32PN
MS27505E19B32PN is a MIL-DTL-38999 Series I rear box-mount receptacle. The catalog configuration uses shell 19, insert 32, with 32 contact positions (32×20).
Product number MS27505E19B32PN
- Series
- Series I
- Shell / insert
- 19 / 32
- Contact positions
- 32 positions; 32×20
- Material / finish
- Aluminum alloy; olive drab cadmium over nickel base
Description
MS27505E19B32PN is a MIL-DTL-38999 Series I rear box-mount receptacle. The catalog configuration uses shell 19, insert 32, with 32 contact positions (32×20). The listed contact configuration is P (crimp pin); keying is N. Shell material and finish: Aluminum alloy; olive drab cadmium over nickel base. Keep the complete product number when requesting the offered-unit drawing and contact supply details.
Configuration checklist
- Match the full ordering code and insert face to the supplied drawing.
- Confirm the mating half, contact gender, key position and coupling interface.
- Check shell style, rear configuration, cable exit and any accessory interface.
- Request the documents required for the offered unit; catalog values are not unit test results.
Technical Data
Ordering-code and insert data are catalog references. Electrical, environmental and mating-life values shown as catalog or family figures do not certify the supplied unit. Confirm the exact configuration and required evidence against its controlled drawing.
| Series and shell style | MIL-DTL-38999 Series I; Rear box-mount receptacle |
|---|---|
| Shell size / insert arrangement | 19 / 32 |
| Contact quantity and size mix | 32 positions; 32×20 |
| Coupling | Bayonet |
| Contact / termination | P (crimp pin) |
| Keying / option | N |
| Shell material and finish | Aluminum alloy; olive drab cadmium over nickel base |
