MS27505E23B35PN
MS27505E23B35PN is a MIL-DTL-38999 Series I rear box-mount receptacle. The catalog configuration uses shell size 23, insert arrangement 35, with 100 contact positions (100×22D).
Product number MS27505E23B35PN
- Series
- Series I
- Shell / insert
- 23 / 35
- Contact positions
- 100 positions; 100×22D
- Material / finish
- Aluminum alloy; olive drab cadmium over nickel base
Description
MS27505E23B35PN is a MIL-DTL-38999 Series I rear box-mount receptacle. The catalog configuration uses shell size 23, insert arrangement 35, with 100 contact positions (100×22D). The catalog lists Bayonet coupling and Aluminum alloy; olive drab cadmium over nickel base. Select this reference with the full contact and keying code, panel or harness drawing, and intended mating half.
Configuration checklist
- Match the full ordering code and insert face to the supplied drawing.
- Confirm the mating half, contact gender, key position and coupling interface.
- Check shell style, rear configuration, cable exit and any accessory interface.
- Request the documents required for the offered unit; catalog values are not unit test results.
Technical Data
Ordering-code and insert data are catalog references. Electrical, environmental and mating-life values shown as catalog or family figures do not certify the supplied unit. Confirm the exact configuration and required evidence against its controlled drawing.
| Series and shell style | MIL-DTL-38999 Series I; Rear box-mount receptacle |
|---|---|
| Shell size / insert arrangement | 23 / 35 |
| Contact quantity and size mix | 100 positions; 100×22D |
| Coupling | Bayonet |
| Contact / termination | P (crimp pin) |
| Keying / option | N |
| Shell material and finish | Aluminum alloy; olive drab cadmium over nickel base |
| Accessory thread / shell drawing | 1.3125-18 |
Applications
These are selection and sourcing contexts for the listed catalog configuration. Suitability depends on the equipment interface, operating conditions and supplied-item documentation.
Buyer Q&A
Which shell and insert configuration is listed for MS27505E23B35PN?
The current catalog preparation lists shell 23, insert 35, 100 contact positions with 100×22D. Use the full ordering reference when checking the supplied configuration.
What mounting information matters for MS27505E23B35PN?
The listed shell style is rear box-mount receptacle. The catalog drawing reference is Own 2025 pp.16-18; compare its installation dimensions and rear interface 1.3125-18 with the equipment drawing.
How should a mating half be checked for MS27505E23B35PN?
Check the same MIL-DTL-38999 Series I, shell 23, insert 35 and keying N, with complementary contact gender. Verify the two complete drawings; matching a family name does not establish interchangeability.
What should an RFQ for MS27505E23B35PN include?
Send MS27505E23B35PN, quantity, mating-half reference, mounting or harness drawing, contact/termination requirements and required documents. State any configuration changes separately from the base ordering code.
