MS27505E25B29PN

Product number MS27505E25B29PN

Series: Series I
Shell / insert: 25 / 29
Contact positions: 29 positions; 29×16
Material / finish: Aluminum alloy; olive drab cadmium over nickel base

Request Technical Review View MIL-DTL-38999 Series

Description

MS27505E25B29PN is a MIL-DTL-38999 Series I back-panel box-mount receptacle. The cited catalog lists shell size 25, insert arrangement 29, 29 positions (29×16), and p (crimp pin) termination with bayonet coupling. Confirm the mating half, key position and panel interface against the controlled drawing before ordering. For a cross-reference or compatible-supply review, send the mating code, drawing or clear product photo, quantity, and document requirements. Do not treat family-level catalog data as qualification or acceptance evidence for a supplied unit.

Configuration checklist

Match the full ordering code and insert face to the supplied drawing.
Confirm the mating half, contact gender, key position and coupling interface.
Check shell style, rear configuration, cable exit and any accessory interface.
Request the documents required for the offered unit; catalog values are not unit test results.

Technical Data

Ordering-code and insert data are catalog references. Electrical, environmental and mating-life values shown as catalog or family figures do not certify the supplied unit. Confirm the exact configuration and required evidence against its controlled drawing.

Series and shell style	MIL-DTL-38999 Series I; Rear box-mount receptacle
Coupling	Bayonet
Rear configuration / finish codes	E rear / B finish
Shell size / insert arrangement	25 / 29
Contact quantity and size mix	29 positions; 29×16
Contact type / termination	P (crimp pin)
Keying / option	N
Shell material and finish	Aluminum alloy; olive drab cadmium over nickel base
Insert service rating	I
Catalog withstand voltage at sea level	1800 V
Catalog withstand voltage at 21 km	1000 V
Catalog current rating by contact size	16: 13 A/contact
Catalog contact resistance by size	16: ≤2.5 mΩ
Catalog operating temperature	-65 to +175 °C
Catalog salt spray	500 h
Family catalog mating life	≥500 mating cycles (family catalog)
Family catalog insulation resistance	≥5000 MΩ normal; ≥100 MΩ humid (family, own pp.5/28)
Family catalog shell continuity	≤2.5 mΩ
Family catalog EMI shielding	≥85 dB (100 MHz–1 GHz); ≥50 dB (1–10 GHz) (family, own pp.5/28)
Catalog drawing reference	Own 2025 pp.16-18
Rear drawing callout (reference only)	Catalog drawing callout 1.4375-18; drawing reference only, not asserted as a rear-accessory interface. Confirm applicability against the controlled drawing.
