MS27473T10B04SB-H
MS27473T10B04SB-H is a Series II straight plug with bayonet coupling. It uses shell10, insert10-04 with four size20 positions, an olive-drab-cadmium aluminum shell, socket contacts, alternateB keying and the supplier -H solder option.
Product number MS27473T10B04SB-H
- Series
- Series II
- Shell / insert
- 10 / 04
- Contact positions
- 4 positions; 4×20
- Material / finish
- Aluminum alloy; olive drab cadmium over nickel base
Description
MS27473T10B04SB-H is a Series II straight plug with bayonet coupling. It uses shell10, insert10-04 with four size20 positions, an olive-drab-cadmium aluminum shell, socket contacts, alternateB keying and the supplier -H solder option.
Configuration checklist
- Match the full ordering code and insert face to the supplied drawing.
- Confirm the mating half, contact gender, key position and coupling interface.
- Check shell style, rear configuration, cable exit and any accessory interface.
- Request the documents required for the offered unit; catalog values are not unit test results.
Technical Data
Ordering-code and insert data are catalog references. Electrical, environmental and mating-life values shown as catalog or family figures do not certify the supplied unit. Confirm the exact configuration and required evidence against its controlled drawing.
| Series and shell style | MIL-DTL-38999 Series II; Straight plug |
|---|---|
| Shell size / insert arrangement | 10 / 04 |
| Contact quantity and size mix | 4 positions; 4×20 |
| Coupling | Bayonet |
| Shell material and finish | Aluminum alloy; olive drab cadmium over nickel base |
| Contact / termination | S (socket); solder (-H supplier option) |
| Keying / option | B (alternate keying) |
Applications
These are selection and sourcing contexts for the listed catalog configuration. Suitability depends on the equipment interface, operating conditions and supplied-item documentation.
Buyer Q&A
Which body and insert are identified for MS27473T10B04SB-H?
The Series II bayonet plug body uses shell10 and insert10-04, with 4 catalog positions (4×20).
How is the installation checked for MS27473T10B04SB-H?
The listed configuration is a straight plug. Check coupling clearance, rear termination space and the complete mating-half drawing for shell 10; confirm any backshell interface with the selected accessory drawing.
How are contacts and keying specified for MS27473T10B04SB-H?
The full SB-H suffix identifies socket contacts, alternateB keying and the supplier solder option.
What should an RFQ include for MS27473T10B04SB-H?
Include MS27473T10B04SB-H, quantity, complete contact/keying configuration, mating-half part number, installation drawing and required offered-unit documents.
