MIL-DTL-38999 Series III · catalog configuration
D38999/26KC04B1N
D38999/26KC04B1N is a supplier-listed Series III style straight-plug configuration. The verified body uses shell13, four-position insert04 and K passivated stainless steel. Use the complete B1N code to select the special-contact assembly and mating drawing.
Product number D38999/26KC04B1N
- Series
- Series III
- Shell / insert
- 13 / 04
- Contact positions
- 4 positions; special-contact option B1
- Material / finish
- Passivated stainless steel (K ordering definition)
Description
D38999/26KC04B1N is a supplier-listed Series III style straight-plug configuration. The verified body uses shell13, four-position insert04 and K passivated stainless steel. Use the complete B1N code to select the special-contact assembly and mating drawing.
Configuration checklist
- Match the full ordering code and insert face to the supplied drawing.
- Confirm the mating half, contact gender, key position and coupling interface.
- Check shell style, rear configuration, cable exit and any accessory interface.
- Request the documents required for the offered unit; catalog values are not unit test results.
Technical Data
Ordering-code and insert data are catalog references. Electrical, environmental and mating-life values shown as catalog or family figures do not certify the supplied unit. Confirm the exact configuration and required evidence against its controlled drawing.
| Series and shell style | Series III style; straight plug |
|---|---|
| Shell size / insert arrangement | 13 / 04 |
| Contact quantity and size mix | 4 positions; special-contact option B1 |
| Coupling | Triple-start threaded |
| Contact / termination | B1 (complete supplier contact-option code retained) |
| Keying / option | N (normal keying code) |
| Shell material and finish | Passivated stainless steel (K ordering definition) |
Applications
These are selection and sourcing contexts for the listed catalog configuration. Suitability depends on the equipment interface, operating conditions and supplied-item documentation.
Buyer Q&A
Which body configuration is listed for D38999/26KC04B1N?
The listed body uses shell13, insert04 and four positions, with K passivated stainless steel.
How should the mating interface be selected for D38999/26KC04B1N?
The listed configuration is a straight plug. Check coupling clearance, rear termination space and the complete mating-half drawing for shell 13; confirm any backshell interface with the selected accessory drawing.
How should the B1 contact option be specified for D38999/26KC04B1N?
Retain the full B1 supplier code. The supplied contact system and termination are selected using its complete contact drawing and assembly specification.
What should an RFQ include for D38999/26KC04B1N?
Include D38999/26KC04B1N, quantity, the complete mating-half code, required contact system, assembly drawing and supplied-unit documents.
Similar Products
Compare adjacent catalog configurations and confirm mating, keying and rear interface by drawing.
D38999/26KC04B1N · RFQ
Send the exact drawing and mating requirement
Include the mating part, cable or panel details, quantity and documentation required for your project.
