MIL-DTL-38999 Series III · catalog configuration
D38999/26FD35SNM
D38999/26FD35SNM is a Series III straight-plug supplier configuration. The catalog body uses shell15, insert35 and37 contact positions (37×22D), socket configurationS and normal keyingN. Retain the complete SNM supplier code in the RFQ.
Product number D38999/26FD35SNM
- Series
- Series III
- Shell / insert
- 15 / 35
- Contact positions
- 37 positions; 37×22D
- Material / finish
- Aluminum alloy; electroless nickel
Description
D38999/26FD35SNM is a Series III straight-plug supplier configuration. The catalog body uses shell15, insert35 and37 contact positions (37×22D), socket configurationS and normal keyingN. Retain the complete SNM supplier code in the RFQ. Use the complete supplier configuration and controlled drawing to confirm the offered unit.
Configuration checklist
- Match the full ordering code and insert face to the supplied drawing.
- Confirm the mating half, contact gender, key position and coupling interface.
- Check shell style, rear configuration, cable exit and any accessory interface.
- Request the documents required for the offered unit; catalog values are not unit test results.
Technical Data
Ordering-code and insert data are catalog references. Electrical, environmental and mating-life values shown as catalog or family figures do not certify the supplied unit. Confirm the exact configuration and required evidence against its controlled drawing.
| Series and shell style | MIL-DTL-38999 Series III; Straight plug |
|---|---|
| Shell size / insert arrangement | 15 / 35 |
| Contact quantity and size mix | 37 positions; 37×22D |
| Coupling | Triple-start threaded, self-locking |
| Contact / termination | S (socket contact configuration) |
| Keying / option | N (normal keying) |
| Shell material and finish | Aluminum alloy; electroless nickel |
Applications
These are selection and sourcing contexts for the listed catalog configuration. Suitability depends on the equipment interface, operating conditions and supplied-item documentation.
Buyer Q&A
Which insert configuration is listed for D38999/26FD35SNM?
The catalog body configuration is15-35 with37 positions (37×22D). Supplied contact population is confirmed with the offered unit.
Which full product code should be quoted for D38999/26FD35SNM?
The listed configuration is a straight plug. Check coupling clearance, rear termination space and the complete mating-half drawing for shell 15; confirm any backshell interface with the selected accessory drawing.
How should the mating interface be checked for D38999/26FD35SNM?
Compare SeriesIII shell15, insert35, keyingN and complementary contacts with the full mating-half drawing.
What should an RFQ include for D38999/26FD35SNM?
Include D38999/26FD35SNM, quantity, mating-half code, harness drawing, required supplied contacts and documents.
Similar Products
Compare adjacent catalog configurations and confirm mating, keying and rear interface by drawing.
D38999/26FD35SNM · RFQ
Send the exact drawing and mating requirement
Include the mating part, cable or panel details, quantity and documentation required for your project.
