M85049/18 connector accessory · catalog configuration
M85049/1813W03
M85049/1813W03 is a straight environmental EMI/RFI backshell configuration in the M85049/18 catalog family. Its ordering code specifies accessory shell13, standard length, W olive-drab-cadmium finish and clamp03 for a cable diameter of6.35–9.53mm. Match the GroupL connector interface and cable fit to the installation drawing.
Product number M85049/1813W03
- Category
- Straight backshell + clamp
- Accessory shell
- 13
- Catalog family
- M85049/18
- Finish
- W; olive-drab cadmium over electroless nickel
Description
M85049/1813W03 is a straight environmental EMI/RFI backshell configuration in the M85049/18 catalog family. Its ordering code specifies accessory shell13, standard length, W olive-drab-cadmium finish and clamp03 for a cable diameter of6.35–9.53mm. Match the GroupL connector interface and cable fit to the installation drawing. Verify connector clearance, cable outside diameter, shield termination and sealing requirements with the exact accessory drawing.
Configuration checklist
- Match the full cable clamp ordering code to the supplied drawing.
- Confirm the connector rear interface, cable fit and locking option.
- Check shell style, rear configuration, cable exit and any accessory interface.
- Request the documents required for the offered unit; catalog values are not unit test results.
Technical Data
The table identifies the catalog ordering configuration. Use the controlled accessory drawing to confirm the connector rear interface, cable fit and mounting clearance.
| Accessory type | Straight environmental EMI/RFI backshell (catalog category) |
|---|---|
| Connector group | Group L; MIL-DTL-38999 Series III / IV |
| Accessory shell size | 13 (C) |
| Length option | Standard length |
| Finish code | W; olive-drab cadmium over electroless nickel |
| Shell material | Aluminum |
| Clamp size | 03 |
| Cable diameter range | 6.35–9.53 mm (0.25–0.38 in) |
Applications
These are selection and sourcing contexts for the listed catalog configuration. Suitability depends on the equipment interface, operating conditions and supplied-item documentation.
Buyer Q&A
What is the accessory category for M85049/1813W03?
The M85049/18 catalog identifies a straight environmental EMI/RFI spin-coupling backshell for GroupL connector interfaces. Confirm supplied-unit construction and required documents against its controlled drawing.
Which connector and shell interface is listed for M85049/1813W03?
GroupL covers MIL-DTL-38999 Series III and IV. The accessory shell13 code corresponds to connector shell13/C; verify the complete rear interface and installation drawing.
What do W and03 specify for M85049/1813W03?
W specifies an aluminum body with olive-drab cadmium over electroless nickel. Clamp03 lists a cable diameter range of0.25–0.38in (6.35–9.53mm); check the actual cable and assembly drawing.
What should an RFQ include for M85049/1813W03?
Include M85049/1813W03, connector part number, cable outside diameter, shielding and sealing requirements, quantity and required supplied-unit documents.
