MIL-DTL-38999 Series I · catalog configuration
MS27505E13B08PN
MS27505E13B08PN is a MIL-DTL-38999 Series I rear box-mount receptacle. The catalog ordering configuration lists shell size 13, insert arrangement 08, and 8 positions (8×20).
Product number MS27505E13B08PN
- Series
- Series I
- Shell / insert
- 13 / 08
- Contact positions
- 8 positions; 8×20
- Material / finish
- Aluminum alloy; olive drab cadmium over nickel base
Description
MS27505E13B08PN is a MIL-DTL-38999 Series I rear box-mount receptacle. The catalog ordering configuration lists shell size 13, insert arrangement 08, and 8 positions (8×20). The catalog lists bayonet coupling, crimp pin contacts, keying N, and an aluminum-alloy shell with olive drab cadmium over a nickel base. Confirm the offered unit, contact population, mounting interface, and required documents against its controlled drawing.
Configuration checklist
- Match the full ordering code and insert face to the supplied drawing.
- Confirm the mating half, contact gender, key position and coupling interface.
- Check shell style, rear configuration, cable exit and any accessory interface.
- Request the documents required for the offered unit; catalog values are not unit test results.
Technical Data
Ordering-code and insert data are catalog references. Electrical, environmental and mating-life values shown as catalog or family figures do not certify the supplied unit. Confirm the exact configuration and required evidence against its controlled drawing.
| Series and shell style | MIL-DTL-38999 Series I; rear box-mount receptacle |
|---|---|
| Shell size / insert arrangement | 13 / 08 |
| Contact quantity and size mix | 8 positions; 8×20 |
| Coupling | Bayonet |
| Contact gender / termination | P (crimp pin) |
| Keying / option | N |
| Shell material and finish | Aluminum alloy; olive drab cadmium over nickel base |
| Ordering-code rear / finish | E rear / B finish |
| Insert service rating | I |
| Catalog withstand voltage at sea level | 1800 V |
| Catalog withstand voltage at 21 km | 1000 V |
| Catalog current rating by contact size | 20: 7.5 A/contact |
| Catalog contact resistance by size | 20: ≤5 mΩ |
| Catalog operating temperature | -65 to +175 °C |
| Catalog salt spray | 500 h |
| Family catalog mating life | ≥500 mating cycles (family reference) |
| Accessory interface / shell drawing | 0.6875-24 |
| Catalog drawing reference | Internal 2025 catalog, pp. 16–18; insert row 12 on p. 104 |
| Catalog source boundary | Ordering configuration and family references only; not SKU-specific test or qualification evidence. |
Applications
These are selection and sourcing contexts for the listed catalog configuration. Suitability depends on the equipment interface, operating conditions and supplied-item documentation.
Buyer Q&A
Which shell and insert configuration is listed for MS27505E13B08PN?
The catalog reference lists Series I shell 13 and insert arrangement 08, with 8 positions (8×20). Confirm the supplied configuration against its controlled drawing.
What contact option is listed for MS27505E13B08PN?
The ordering code is listed with P (crimp pin) and keying N. The reference photo has a protective insert face that obscures the contact details, so verify the supplied contacts against the controlled drawing.
What mounting interface should be checked for MS27505E13B08PN?
The catalog identifies a rear box-mount receptacle with a 0.6875-24 interface. Compare the complete installation drawing with the equipment panel before selection.
What should an RFQ for MS27505E13B08PN include?
Include the complete part number, quantity, mating-half reference, panel or harness drawing, contact configuration, and required documents.
Similar Products
Compare adjacent catalog configurations and confirm mating, keying and rear interface by drawing.
