Reference view from this SKU's source folder. Confirm supplied contacts and options against the controlled drawing.
MIL-DTL-38999 Series III · catalog configuration
D38999/26WH06SN
D38999/26WH06SN is a MIL-DTL-38999 Series III straight plug. The listed configuration uses shell H (23) and insert arrangement 06.
Product number D38999/26WH06SN
- Series
- Series III
- Shell / insert
- H (23) / 06
- Contact positions
- 6 positions with size-8 twinax contacts per catalog; special-contact electrical ratings require the controlled drawing.
- Material / finish
- Aluminum alloy; olive drab cadmium
Description
D38999/26WH06SN is a MIL-DTL-38999 Series III straight plug. The listed configuration uses shell H (23) and insert arrangement 06. The catalog lists Triple-start threaded, self-locking coupling and Aluminum alloy; olive drab cadmium. Use the complete ordering code when checking the mounting interface and mating half. 6 positions with size-8 twinax contacts per catalog; special-contact electrical ratings require the controlled drawing. Confirm special-contact ratings and the supplied contact population from the controlled drawing; no unit-specific qualification is implied here.
Configuration checklist
- Match the full ordering code and insert face to the supplied drawing.
- Confirm the mating half, contact gender, key position and coupling interface.
- Check shell style, rear configuration, cable exit and any accessory interface.
- Request the documents required for the offered unit; catalog values are not unit test results.
Technical Data
Ordering-code and insert data are catalog references. Electrical, environmental and mating-life values shown as catalog or family figures do not certify the supplied unit. Confirm the exact configuration and required evidence against its controlled drawing.
| Series and shell style | MIL-DTL-38999 Series III; Straight plug |
|---|---|
| Shell size / insert arrangement | H (23) / 06 |
| Contact quantity and size mix | 6 positions with size-8 twinax contacts per catalog; special-contact electrical ratings require the controlled drawing. |
| Coupling | Triple-start threaded, self-locking |
| Ordering-code service / finish suffix | W |
| Contact type / termination | S (crimp socket) |
| Keying / option | N |
| Shell material and finish | Aluminum alloy; olive drab cadmium |
| Catalog source boundary | Ordering configuration only; confirm offered-unit details and required documents against its controlled drawing. |
Applications
These are selection and sourcing contexts for the listed catalog configuration. Suitability depends on the equipment interface, operating conditions and supplied-item documentation.
Buyer Q&A
Which shell and insert configuration is listed for D38999/26WH06SN?
The catalog reference lists Series III shell H (23), insert arrangement 06. Check the complete ordering code against the supplied drawing.
Does the insert position count confirm the contacts supplied with D38999/26WH06SN?
No. The listed insert arrangement describes positions. Confirm installed contacts, special-contact options and electrical ratings against the offered unit's controlled drawing.
How should a mating half for D38999/26WH06SN be checked?
Compare the complete Series III part numbers and controlled drawings, including shell size, insert arrangement, keying, coupling and complementary contact gender. Matching the connector family alone does not establish interchangeability.
What should an RFQ for D38999/26WH06SN include?
Include D38999/26WH06SN, quantity, mating-half reference, mounting or harness drawing, required contact configuration and required documents. Confirm any special-contact ratings from the offered-unit drawing.
