MIL-DTL-38999 Series III · catalog configuration
D38999/26FB98SA
D38999/26FB98SA is a MIL-DTL-38999 Series III straight plug. The catalog configuration lists shell B (11), insert arrangement 98, with 6 contact positions (6×20).
Product number D38999/26FB98SA
- Series
- Series III
- Shell / insert
- B (11) / 98
- Contact positions
- 6 positions; 6×20
- Material / finish
- Aluminum alloy; electroless nickel
Description
D38999/26FB98SA is a MIL-DTL-38999 Series III straight plug. The catalog configuration lists shell B (11), insert arrangement 98, with 6 contact positions (6×20). The catalog lists Triple-start threaded, self-locking coupling and Aluminum alloy; electroless nickel. Confirm the complete ordering code, mounting interface and mating half against the controlled drawing.
Configuration checklist
- Match the full ordering code and insert face to the supplied drawing.
- Confirm the mating half, contact gender, key position and coupling interface.
- Check shell style, rear configuration, cable exit and any accessory interface.
- Request the documents required for the offered unit; catalog values are not unit test results.
Technical Data
Ordering-code and insert data are catalog references. Electrical, environmental and mating-life values shown as catalog or family figures do not certify the supplied unit. Confirm the exact configuration and required evidence against its controlled drawing.
| Series and shell style | MIL-DTL-38999 Series III; Straight plug |
|---|---|
| Shell size / insert arrangement | B (11) / 98 |
| Contact quantity and size mix | 6 positions; 6×20 |
| Coupling | Triple-start threaded, self-locking |
| Contact / termination | S (crimp socket) |
| Keying / option | A |
| Shell material and finish | Aluminum alloy; electroless nickel |
| Accessory thread / shell drawing | M 15×1-6g |
Applications
These are selection and sourcing contexts for the listed catalog configuration. Suitability depends on the equipment interface, operating conditions and supplied-item documentation.
Buyer Q&A
What configuration is listed for D38999/26FB98SA?
The catalog lists shell B (11), insert 98, 6 contact positions (6×20) and S (crimp socket). Confirm the offered configuration against its controlled drawing.
What shell style and interface should be checked for D38999/26FB98SA?
The catalog lists a straight plug with Triple-start threaded, self-locking coupling. Compare the installation dimensions and M 15×1-6g interface against the equipment drawing.
How should a mating half be selected for D38999/26FB98SA?
Check the full D38999/26FB98SA ordering code, shell B (11), insert 98, keying A and complementary contact gender against both controlled drawings.
What should an RFQ for D38999/26FB98SA include?
Include D38999/26FB98SA, quantity, mating-half reference, installation or harness drawing, required documents, and any separately specified options.
Similar Products
Compare adjacent catalog configurations and confirm mating, keying and rear interface by drawing.
D38999/26FB98SA · RFQ
Send the exact drawing and mating requirement
Include the mating part, cable or panel details, quantity and documentation required for your project.
