D38999/24FJ61SN
D38999/24FJ61SN is a MIL-DTL-38999 Series III jam-nut receptacle. The catalog configuration uses shell size J (25), insert arrangement 61, with 61 contact positions (61×20).
Product number D38999/24FJ61SN
- Series
- Series III
- Shell / insert
- J (25) / 61
- Contact positions
- 61 positions; 61×20
- Material / finish
- Aluminum alloy; electroless nickel
Description
D38999/24FJ61SN is a MIL-DTL-38999 Series III jam-nut receptacle. The catalog configuration uses shell size J (25), insert arrangement 61, with 61 contact positions (61×20). The catalog lists Triple-start threaded, self-locking coupling and Aluminum alloy; electroless nickel. Select this reference with the full contact and keying code, panel or harness drawing, and intended mating half.
Configuration checklist
- Match the full ordering code and insert face to the supplied drawing.
- Confirm the mating half, contact gender, key position and coupling interface.
- Check shell style, rear configuration, cable exit and any accessory interface.
- Request the documents required for the offered unit; catalog values are not unit test results.
Technical Data
Ordering-code and insert data are catalog references. Electrical, environmental and mating-life values shown as catalog or family figures do not certify the supplied unit. Confirm the exact configuration and required evidence against its controlled drawing.
| Series and shell style | MIL-DTL-38999 Series III; Jam-nut receptacle |
|---|---|
| Shell size / insert arrangement | J (25) / 61 |
| Contact quantity and size mix | 61 positions; 61×20 |
| Coupling | Triple-start threaded, self-locking |
| Ordering-code service / finish | F |
| Contact type / termination | S (crimp socket) |
| Keying / option | N |
| Shell material and finish | Aluminum alloy; electroless nickel |
| Catalog insert service rating | I |
| Catalog withstand voltage at sea level | 1800 V |
| Catalog withstand voltage at 21 km | 1000 V |
| Catalog contact current per contact | 20: 7.5 A/contact |
| Catalog contact resistance | 20: ≤5 mΩ |
| Catalog operating temperature | -65 to +200 °C |
| Catalog salt spray | 48 h |
| Family catalog mating life | ≥500 mating cycles (family catalog) |
Applications
These are selection and sourcing contexts for the listed catalog configuration. Suitability depends on the equipment interface, operating conditions and supplied-item documentation.
Buyer Q&A
Which shell and insert configuration is listed for D38999/24FJ61SN?
The current catalog preparation lists shell J (25), insert 61, 61 contact positions with 61×20. Use the full ordering reference when checking the supplied configuration.
What mounting information matters for D38999/24FJ61SN?
Confirm the mounting dimensions and rear interface using the drawing for the exact ordering reference and the equipment drawing.
How should a mating half be checked for D38999/24FJ61SN?
Check the same MIL-DTL-38999 Series III, shell J (25), insert 61 and keying N, with complementary contact gender. Verify the two complete drawings; matching a family name does not establish interchangeability.
What should an RFQ for D38999/24FJ61SN include?
Send D38999/24FJ61SN, quantity, mating-half reference, mounting or harness drawing, contact/termination requirements and required documents. State any configuration changes separately from the base ordering code.
