MIL-DTL-38999 Series III · catalog configuration
D38999/20FF32SNH
D38999/20FF32SNH is a MIL-DTL-38999 Series III wall-mount receptacle. The catalog configuration uses shell 19, insert 32, with 32 contact positions (32×20).
Product number D38999/20FF32SNH
- Series
- Series III
- Shell / insert
- 19 / 32
- Contact positions
- 32 positions; 32×20
- Material / finish
- Aluminum alloy; electroless nickel
Description
D38999/20FF32SNH is a MIL-DTL-38999 Series III wall-mount receptacle. The catalog configuration uses shell 19, insert 32, with 32 contact positions (32×20). The listed contact configuration is S (solder socket; supplier full-model listing); keying is N. Shell material and finish: Aluminum alloy; electroless nickel. Keep the complete product number when requesting the offered-unit drawing and contact supply details.
Configuration checklist
- Match the full ordering code and insert face to the supplied drawing.
- Confirm the mating half, contact gender, key position and coupling interface.
- Check shell style, rear configuration, cable exit and any accessory interface.
- Request the documents required for the offered unit; catalog values are not unit test results.
Technical Data
Ordering-code and insert data are catalog references. Electrical, environmental and mating-life values shown as catalog or family figures do not certify the supplied unit. Confirm the exact configuration and required evidence against its controlled drawing.
| Series and shell style | MIL-DTL-38999 Series III; Wall-mount receptacle |
|---|---|
| Shell size / insert arrangement | 19 / 32 |
| Contact quantity and size mix | 32 positions; 32×20 |
| Coupling | Triple-start threaded, self-locking |
| Contact / termination | S (solder socket; supplier full-model listing) |
| Keying / option | N |
| Shell material and finish | Aluminum alloy; electroless nickel |
Applications
These are selection and sourcing contexts for the listed catalog configuration. Suitability depends on the equipment interface, operating conditions and supplied-item documentation.
Buyer Q&A
Which insert configuration is listed for D38999/20FF32SNH?
The catalog lists shell 19, insert 32, with 32 positions (32×20). Confirm supplied contact population with the offered-unit drawing.
What installation information matters for D38999/20FF32SNH?
This is a wall-mount receptacle in shell 19. Compare flange mounting, panel opening, seal placement and rear clearance against the controlled installation drawing.
What contact and keying configuration is listed for D38999/20FF32SNH?
The listed contact configuration is S (solder socket; supplier full-model listing); keying is N. Compare the complete mating-half code and drawings.
What should an RFQ for D38999/20FF32SNH include?
Send the complete D38999/20FF32SNH product number, quantity, mating-half code, installation drawing, required supplied contacts and documents.
